Agricultural Meteorological Station (YT-QXNY)

Product model: YT-QXNY

Product classification: Environmental monitoring instruments

Application areas: Agriculture, greenhouse, greenhouse, forestry, scientific research, and other fields

Product Introduction:

The farmland microclimate observation station is a small automatic meteorological station designed for monitoring the energy and substance exchange between the climate, agricultural biology, and agricultural production in agricultural ecological environments (such as farmland, orchards, greenhouses, livestock houses, etc.), as well as agricultural production activity environments (such as sun drying fields, spraying, agricultural product storage, etc.).

Technical parameters:

Multiple access: up to 16 meteorological sensors can be connected, including wind speed, direction, rainfall, temperature, humidity, air pressure, radiation, etc

Processor: The core adopts a 16 bit microprocessor, and the system clock can reach up to 36MHz, with ultra fast execution speed

Remote control: can remotely burn and write programs, facilitating system improvement and upgrading

Human machine interface: A user-friendly interface that allows for direct parameter settings on the panel

Anti interference: Input and output adopt photoelectric isolation, with strong anti-interference ability

High precision: using 12 bit A/D for analog-to-digital conversion, with high conversion accuracy and small errors

Communication mode: Multiple methods such as RS232, RS48, GPRS, USB, and data radio can be used to communicate with the upper computer

Data export: Customizable external data storage on USB flash drives, achieving massive data storage

Display format: Graphic dot matrix LCD 128X64DOT

Data storage capacity: 16M

Data interface: 16 channel analog signal, 4 RS232RS485 channels, 2 relay outputs

Working power supply: AC220V, DC12V, solar battery

Power consumption: The overall power consumption of the machine shall not exceed 2W

Environmental temperature -20~70 ℃

Power supply: 12V

Protection level: IP65

Advantages and characteristics:

1. A complete agricultural meteorological system suitable for agricultural production and scientific research purposes;

2. Flexible combination of intelligent micro meteorological multi in one sensors and extended elements;

3. Integrating data collection and wireless communication, the collection density can be set by oneself;

4. It can be used for single site applications or network deployment, with wireless data transmission;

5. Support communication/solar power supply methods;

6. Large capacity data storage
